    4000bph Cap Tightening Machine Glass Bottle , 3000bph Rotary Capping Machine

    3000-4000BPH Plastic Glass Bottle Rotary Capping Machine


    Description:

    This machine combines bottle-in, cap-sorter, cap-elevator, capping and bottle-out altogether in one. The rotary structure , catching the lid in the certain position, stable and reliable. It does no harm to bottle and lid . High capping efficiency, high qualified rate of capping, and wide application which enjoys good competitiveness that can be compared with foreign products. It is applicable to varies size of glass and plastic bottles and caps. Its operation principle is by means of the scratching plate to cap the the lid when the bottle rotaryed. The whole machine is controlled by the PLC, touch screen interface and convenient operation.


    Features:

    This machine has eight mechanical hands ,dispatches caps in high speed with no inverse cap ,which can be used in various configurations containers ,irregular containers . It can be divided into scrape capping and grasp capping according to different caps . Supply cap machine and mechanical hands working with synch . When cap tighten finished , bottle and cap relatively stop . Clutch separate , bottles and cap are not injured .
    The each lid-revolving head has a clutch to ensure the tightened lid not to damage. It suits for the all kinds of cylinder-shaped bottle’s lid-revolving for the industry such as foodstuff, pharmacy, daily chemicals, pesticide and chemical industry.


    Parameter setting:

    1Applicable bottleDiameter: 40100mm,Height 80280mm
    2Cap SpecificationDiameter : 15-50mm Cap height: 15-35mm
    3Capping Head8
    4Capacity≤6000 bottles/hour
    5Capping qualified rate≥99%
    6Air Pressure0.60.8MPA
    7Power Source380V,50HZ
    8Power3KW
    9External Dimension2200×1360×2400(L×W×H)mm
    10Weight1600Kg

    Configure:​

    No .NameBrandCountryQty
    1Reducer motorZiguangChina1
    2Power buttonSchneiderFrance1
    3Frequency inverterSchneiderFrance2
    4Sensor for bottlesOPTEXJapan1
    5Sensor for capsOmronJapan1
    6Cap sort motorZiguangChina1

    Pictures:

    4000bph Cap Tightening Machine Glass Bottle , 3000bph Rotary Capping Machine


    4000bph Cap Tightening Machine Glass Bottle , 3000bph Rotary Capping Machine


    4000bph Cap Tightening Machine Glass Bottle , 3000bph Rotary Capping Machine


    4000bph Cap Tightening Machine Glass Bottle , 3000bph Rotary Capping Machine
