Fully Automatic Hot Canned Salad dressing Bottle Filling Sauce
Filling Machine
Description
Fully Automatic Hot Canned Salad dressing Bottle Filling Sauce
Filling Machine is an extremely flexible piston fillers capable of
filling accurately and rapidly a wide variety of products from low
viscosity liquids to high viscosity paste or cream with or without
chunks or particulates. Widely used in food industry(e.g.,paste
filling machine, butter filling machine, jam filling machine,
ketchup filling machine, honey filling machine, edible oil filling
machine, sauce filling machine etc); household product
industry(e.g.,shampoo filling machine, liquid soap filling machine,
liquid detergent filling machine, hand wash filling machine etc),
personal care industry(e.g.,cream filling machine, lotion filling
machine, gel filling machine, perfume filling machine etc);
Chemical industry(e.g., grease filling machine, lubricant filling
machine etc); pharmaceutical industry(e.,g ointment filling
machine, e liquid filling machine etc).
Suitable For Filling: Sauces / Ketchup / Salad Dressing / Honey / Jam Sauce / Bean
Paste / Viscous Food ...Etc kinds Products
Feature:
1. the machine produced according to GMP standards , all piping
connections using quick way to disassemble and clean convenient
location and contact with the material exposed parts are made of
high quality stainless steel , machine safety, environmental
protection , health, beauty, able to adapt a variety of work in
different environments.
2.The machine adopts PLC and touch screen automation control, with
accurate measurement, advanced structure, smooth operation, low
noise, large adjustment range, the filling speed, etc.
3.Filling lancers driven by cylinder has diving filling mode, and
the variable speed filling matched. This has effectively reduced
foaming when filling easy foaming materials and prevented the
pollution to the bottle. Meanwhile a liquid holder which is
controlled by an individual cylinder is installed under the filling
nozzles. It can avoid the pollution to the bottle and cylinder such
spare parts after the filling nozzle are OFF. At present, only our
company uses the patented technology.
Parameters:
| Capacity | ≤2000 bottles/hour |
| Applicable Bottle Type | 1. 1L Height 190-200mm,width 135-145mm,thickness 55mm. |
| Bottle’s mouth diameter | 1L diameter 35-45mm,machine design according to customer bottle
|
| Filling range | 100ml-5000ML |
| Precision | 100ml-5000ml)±0.5% |
| Air pressure | 0.6～0.8 MPA |
| Air consumption | 120L/minute |
| Power Source | ～380V,50HZ |
| Power | 2.5KW |
| External Dimension | 2440×1150×2300mm(L×W×H) |
| Weight | About 1850Kg |
| Production line height | 850mm±50mm |
| Filling materials | Viscosity liquid |
| Bottle feed direction | From left to right |
Details:
