Lubricant Engine Bottling High Quality Machine Automatic 600ml Seed
Oil Packing Lubricant Oil Motor Antifreeze Filling
Description
Lubricant Engine Bottling High Quality Machine Automatic 600ml Seed
Oil Packing Lubricant Oil Motor Antifreeze Filling is an extremely
flexible piston fillers capable of filling accurately and rapidly a
wide variety of products from low viscosity liquids to high
viscosity paste or cream with or without chunks or particulates.
Widely used in food industry(e.g.,paste filling machine, butter
filling machine, jam filling machine, ketchup filling machine,
honey filling machine, edible oil filling machine, sauce filling
machine etc); household product industry(e.g.,shampoo filling
machine, liquid soap filling machine, liquid detergent filling
machine, hand wash filling machine etc), personal care
industry(e.g.,cream filling machine, lotion filling machine, gel
filling machine, perfume filling machine etc); Chemical
industry(e.g., grease filling machine, lubricant filling machine
etc); pharmaceutical industry(e.,g ointment filling machine, e
liquid filling machine etc).
Automatic linear piston filler is designed for completely
automatic, multiple position, inline dispensing of liquids and
pastes in volume ranging from 50ml to 1000m per cycle. Available in
6, 8, 10 ,12 and 16 nozzle configurations to match specific
production requirements, Dual lane option is available to increase
production by 100% while preserving valuable line space.
The servo motor control belt drives the submerged filling mode of
the filling head operation. With the set variable speed filling
function, the filling head rises with the liquid level, and the
liquid level is synchronized, which can reduce the easy foaming.
The production of foam during filling, preventing bottle mouth
pollution caused by material spillage, effectively increasing
production capacity
Suitable for fill : Lubricant Oil / Car Oil / Motor Oil / coolant
liquid / engine oil / Lubricanting Oil kinds Products
Filling Range : 50ml -1000ml
1L -5L
4L -20L
208L / 220L -1000L
Speed can be choosen : from 1000BPH-6000BPH (basic on 1L )
contact us for more details
Feature:
This non-metal filling machine specially designed for strong acid
and alkali product, such as: hydrochloric acid products bleach.
1. PLC controlled, friendly touch screen control.
2. Famous brand electrical and pneumatic components used to
guarantee machines quality and long life service time.
3. Vacuum suck back for dripping can be special designed for foamy
product.
4. All wetted parts are made of non-metal materials,
anti-corrosion.
5. Not only whole filling heads can be adjusted, but each filling
head can be fine-adjusted respectively.
Parameters:
| Model | ZGP-6H | ZGP-8H | ZGP-10H | ZGP-12H | ZGP-16H |
| Dimension | 2000×710×2200mm (L×W×H) | 2200×710×2200mm (L×W×H) | 2300×710×2200mm (L×W×H) |
| Filling head | 6 | 8 | 10 | 12 | 16 |
| Capacity(500mL) | 1500B/H | 2000 B/H | 2500 B/H | 3000 B/H | 4000 B/H |
| Power | 1KW | 1 KW | 1KW | 1.5KW | 1.5KW |
| Suitable bottle | Diameter:Φ40mm——Φ100mm Height:80mm——280mm |
| Filling accurate | ≤100ml:+ -1.5ml
100-500ml:+ -2ml
500-1000ml:+ -3ml |
| Neck diameter | ≤Φ10mm ( can be designed accordingly) |
| Filling range | 50ml——5000ml (From ZT-PACK) |
| Filling System | Gravity Time Control |
| Air pressure | 0.6Mpa |
| Power supply | 220V ；50HZ / 60HZ |
Details:
